Energotek SP cable ties
Polymer, UV-resistant
For fastening corrugated pipes to supporting structures or for bundling pipes.
01
01 Description
Energotek SP cable ties are made from a flame-retardant polymer compound. The underside of the tie has notches for reliable gripping of the secured objects.
Modifications
- Energotek SP one-lock ties
- Energotek SP two-lock ties
years
0
+
Long service life
(at least 30 years)
(at least 30 years)
Key advantages
- Resistant to aggressive and chemically active environments (seawater, acids, alkalis, etc.)
- UV-resistant
- Dielectric properties: specific volumetric electrical resistance of minimum 1015 Ohm∙cm
- High working load: up to 60 kg
- Fire-safe
02
02 Application area
Fastening corrugated pipes
Intended for fastening corrugated pipes to supporting structures or for bundling pipes. Durable under UV radiation, aggressive and chemically active environments.
03
03 Product range of Energotek SP ties
| Name | Length, mm | Width, mm | Tie design | Working load, kg |
| Energotek SP 6x180 tie | 180 | 6 | One-lock | 35 |
| Energotek SP 9x180 tie | 180 | 9 | Two-lock | 40 |
| Energotek SP 9x260 tie | 260 | 9 | Two-lock | 60 |
| Energotek SP 9x350 tie | 350 | 9 | Two-lock | 60 |
| Energotek SP 9x510 tie | 510 | 9 | Two-lock | 60 |
| Energotek SP 9x610 tie | 610 | 9 | Two-lock | 60 |
| Energotek SP 9x760 tie | 760 | 9 | Two-lock | 60 |
04
04
Example wording for categories
or technical specifications:
Tie
Item name
ENERGOTEK
Trade name
SP
Tie design
6
Tie width
х
180
Tie length
Т85°С
Maximum operating temperature
TU 22.29.29-008-39082310-2020
Technical specification reference number
- ENERGOTEK SP 6х180 T85°C tie TU 22.29.29-008-39082310-2020
Polymer UV-resistant tie
05
05
Main
characteristics
Operating temperature
- Long-term, for the entire service life: -40 to 85°С
