01
01 Description
Intended for securing covers to cable trays. The covers are secured by snapping the clip into the dedicated grooves on the cover and on the underside of the cable tray.
SP type mounting brackets are made from polyamide, SN type mounting brackets are made from stainless steel.
02
02 Product range of clamping brackets
| No. | Name | Tray height, mm |
|---|---|---|
| 1 | Bracket SP 80 | 80 |
| 2 | Bracket SP 100 | 100 |
| 3 | Bracket SP 150 | 150 |
| 4 |
Bracket SN 100 |
100 |
| 5 |
Bracket SN 200 |
200 |
Covers to trays h = 60 mm high do not require brackets.
03
03
Example wording for categories
or technical specifications:
- ENERGOTEK SP 100 UHL1 bracket TU 27.33.13-002-39082310-2020
Mounting bracket made of polyamide, 100 mm high - ENERGOTEK SN 200 UHL1 bracket TU 27.33.13-002-39082310-2020
Mounting bracket made of stainless steel, 200 mm high
